Horton 4100-PLUS - Page 41

Installation
Slide Pull Arm (PF18.05) Negative Reveal (-50mm)
220
180 600
50
50 max
"A"
Dimension "A" [mm] 35 55 75 95
30
PF18.07
50
PF18.08
70
PF18.09
90
PF18.10
Shaft Dimension [mm]
Slide rail flush with frame
