Remove the rubber feet:
1. Close the computer and position it upside down with the front toward you.
2. Insert a tool with no sharp edges between the base enclosure and one end of the rubber feet.
3. Pull up the rubber feet.
To install the rubber feet, refit them on the adhesive backing.
NOTE: The bottoms of the rubber feet are ribbed. These ribs are designed to fit only one way in the
grooves that are in the bottom cover. Make sure the feet are positioned in those grooves during
installation.
Bottom cover
To remove the bottom cover, use this procedure and illustration.
Table 5-2
Bottom cover descriptions and part numbers
Description Spare part number
Bottom cover N96332-001
Before removing the bottom cover, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 30).
2. Remove the rubber feet (see Rubber feet on page 30).
Remove the bottom cover:
Bottom cover
31
