Table 5-3 Battery and system board hook descriptions and part numbers
Description Spare part number
Battery, 3 cell, 41 Whr L97300-005
System board hook L88007-001
Before removing the battery, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 30).
2. Remove the rubber feet (see Rubber feet on page 30).
3. Remove the bottom cover (see Bottom cover on page 31).
Remove the battery:
NOTE: When replacing the battery, be sure to completely reassemble the computer and plug in the
AC adapter before turning the computer on.
1. Remove the five screws (1) securing the battery.
2. Lift the top of the battery (2), and then remove the system board hook (3) while removing the battery
from the computer.
To install the battery, reverse this procedure.
WLAN module
To remove the WLAN module, use this procedure and illustration.
WLAN module
33
