HP 240R G9

3. Remove the WLAN module by pulling it away from the slot at an angle (3).
NOTE: If the WLAN antennas are not connected to the terminals on the WLAN module, the protective
sleeves must be installed on the antenna connectors, as shown in the following illustration.
To install the WLAN module, reverse this procedure.
Memory module
To remove the memory modules, use this procedure and illustration.
Memory module
35
