HP 240R G9

Table 5-7 Speakers description and part number
Description Spare part number
Speakers (includes left and right speakers and cable) L24489-001
Before removing the speakers, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 30).
2. Remove the rubber feet (see Rubber feet on page 30).
3. Remove the bottom cover (see Bottom cover on page 31).
4. Remove the battery (see Battery on page 32).
To remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the tape (2) securing the cable.
3. Lift the speakers (3) out of the computer.
To install the speakers, reverse this procedure.
Touchpad click board and touchpad
To remove the touchpad click board and touchpad, use this procedure and illustration.
