HP 240R G9

3. Lift the fan (3) out of the computer.
To install the fan, reverse this procedure.
System board
To remove the system board, use this procedure and illustration.
Table 5-11
System board descriptions and part numbers
Description Spare part number
System board
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating system
xxxxxx-601: Windows operating system
Intel Core i5-1345U processor N96327-xx1
Intel Core i5-1335U processor N96326-xx1
Intel Core i3-1315U processor N96325-xx1
Before removing the fan, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 30).
2. Remove the rubber feet (see Rubber feet on page 30).
3. Remove the bottom cover (see Bottom cover on page 31).
4. Remove the battery (see Battery on page 32).
42
Chapter 5 Removal and replacement procedures for authorized service provider parts
