3-64
P
erformance T
ests
External 2Mb/s Demux (Options UKL, [USC])
4.
Press
on the
T
est Set
and
set up the
display as sho
wn opposite.
5.
Press
on the
T
est Set
and set
up the
display as
sho
wn opposite.
6.
Press
on the HP 37717C
and set the
display as
sho
wn belo
w
.
TRANSMIT
STRUCTURED SETTINGS
RECEIVE
MAIN SETTINGS
RECEIVE
MAIN SETTINGS
172
