3-240
Performance Tests
Performance Test Record
Pulse Amplitude Ratio 0.95 1.05
Pulse Width Ratio 0.95 1.05
Unbal 34 Mb/s Min Actual Max
3-17 Step 34: +ve Pulse Amp 0.900 V pk 1.100 V pk
+ve Pulse Mask Pass/Fail
-ve Pulse Amp 0.900 V pk 1.100 V pk
-ve Pulse Mask Pass/Fail
Pulse Amplitude Ratio 0.95 1.05
Pulse Width Ratio 0.95 1.05
Unbal 140 Mb/s
(All Ones)
3-19 Step 39: +ve Pulse Amp 0.900 V pk 1.100 V pk
Step 40: +ve Pulse Mask Pass/Fail
Unbal 140 Mb/s
(All Zeros)
3-20 Step 44: -ve Pulse Amp 0.900 V pk 1.100 V pk
Step 45: -ve Pulse Mask Pass/Fail
PDH Multiple TX Outputs
704 kb/s Out 2
(UKK only)
3-24 Step 6: +ve Pulse Amp 2.133 V pk 2.607 V pk
+ve Pulse Width 639 ns 781 ns
Overshoot 0.474 V
Undershoot 0.474 V
704 kb/s Out 3
(UKK only)
Step 7: +ve Pulse Amp 2.133 V pk 2.607 V pk
Table 11 Performance Test Record
Page
No.
Test Description Result
Min Actual Max
To Next Page
