It is often desirable to store measurement settings which are used regularly and be
able to recall those settings at a moments notice. This capability is provided in the
HP 37717C on the OTHER STORED SETTINGS display.
One preset store is provided which cannot be overwritten, STORED SETTING
NUMBER [0], and is used to set the HP 37717C to a known state. The known state
is the FACTORY DEFAULT SETTINGS as listed below.
display (UPDH Option UKK)
Signal 140 Mb/s Clock Sync Internal
Code CMI Pattern 2
23
-1
Termination 75Ω Unbal
display (SPDH Option UKJ)
Settings Main Signal 140 Mb/s
Clock Sync Internal Termination 75Ω Unbal
Line Code CMI Frequency Offset Off
Payload Type Unframed Pattern 2
23
-1
PRBS Polarity INV Test Signal 34 Mb/s
34M Payload Unframed 2M Payload Unframed
2M Payload Unframed 34 Mb 1
8 Mb 1 2 Mb 1
64 kb 1 BG Pattern AIS
User Word 1111111111111111 Error Add Bit
Error Add Rate None
TRANSMIT
TRANSMIT
