HP 37717C Calibration Manual

A-2
Appendix A - Default Settings
display (SDH)
Signal STM-1 Clock Sync Internal
Payload 140 Mb/s Payload Pattern 2
23
-1
TUG3 1 TUG2 1
TU 1 2 Mb/s Pattern 2
15
-1
display (ATM Option UKN)
Signal 34 Mb/s, Internal Clock Sync Internal
Code HDB3 Termination 75Ω Unbal
Cell Stream Distribution F/G Bandwidth 80,000 c/s
B/G 1 Bandwidth 0 B/G 2 Bandwidth 0
B/G 3 Bandwidth 0 F/G Distribution Burst
Burst Size 1 Cell Interface UNI
F/G Payload Cross Cell, 2
15
-1 B/G Stream 1
B/G Payload 00000001 Fill Cells Idle
display (UPDH Option UKK)
Signal 140 Mb/s Test Mode Out of Service
Code CMI Pattern 2^23-1
Termination 75Ω Unbal
TRANSMIT
TRANSMIT
RECEIVE
