116
Storing, Logging and Printing
Viewing the Bar Graph Display
The top row of the display comprises three fields:
Store Memory location in which the displayed bar graph data
is stored. Store can only be changed when the status of
stored results is displayed. See "Recalling Stored
Graph Results " page 113.
Zoom The width, in minutes, of each "bar" in the bar graph,
controlled by / .
Cursor The cursor position in terms of time and date,
controlled by and . The cursor position changes
in steps of 1 second, 1 minute, 15 minutes or 60
minutes dependent upon the ZOOM setting. The cursor
is physically located between the two graphs.
ZOOM IN ZOOM OUT
