145
Using Instrument and Disk Storage
Saving Graphics Results to Disk
Saving Graphics Results to Disk
Description Graphics results can be saved to a file on disk. Two methods of naming
the file, which is created when the measurement is started, are available:
Automatic A filename in the form meas001 is created
automatically without any action from you.
Your Choice You can input a filename of your choice which will
override the automatically generated filename. This
must be entered before the measurement is started. If
the filename you enter already exists, graphics results
will be saved to the automatically generated filename.
This prevents existing files from being overwritten
each time the measurement is started.
HOW TO: 1 Choose GRAPH STORAGE [DISK] and the Graph Storage resolution
required on the display. See “Saving Graphics Results to
Instrument Store” page 112.
If you wish to use the automatically generated filename no further
action is required and the graphics results will be saved on Disk when
the measurement is started.
RESULTS
