118
Storing, Logging and Pr
inting
Viewing the Graphics Err
or and Alarm Summaries
Store can only be changed when the status of stored
results is displayed. See
"Recalling Stored Graph
Results "
page
113.
Start
The start time and date of the test, that produced the
displayed results
.
Stop
The stop time and date of the test, that produced the
displayed results
.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
128
130
Table of Contents
Default Chapter
6
Table of Contents
6
1 Setting the Interfaces
12
Setting PDH Transmit Interface
13
Setting PDH Transmit Binary Interface
15
Setting SONET Transmit Interface
17
Setting Jitter Transmit Interface
20
Setting Wander Transmit Interface
21
Selecting the Physical Transmit Interface for ATM Payloads
23
Setting SONET THRU Mode
25
Using Autosetup
27
Setting PDH Receive Interface
29
Setting PDH Receive Binary Interface
31
Setting SONET Receive Interface
32
Setting Jitter Receive Interface
34
Selecting the Physical Receive Interface for ATM Payloads
36
2 Selecting Test Features
38
Using Transmit Overhead Setup
39
Using Receive Overhead Monitor
41
Setting Overhead Trace Messages
43
Generating Overhead Sequences
44
Using Receive Overhead Capture
46
Adding Frequency Offset to SONET Signal
48
Adding Frequency Offset to the PDH Signal
50
Setting up Signaling Bits
51
Setting Transmit Structured Payload/Test Signal (Options UKJ or 110)
54
Setting Transmit Structured Payload/Test Signal (Options UKJ or
55
Setting Receive Structured Payload/Test Signal
56
Connecting a Telephone Handset
58
Setting Transmit N X 64 Kb/S (N X 56 Kb/S) Structured Payload/Test Signal
59
Setting Receive N X 64 Kb/S (N X 56 Kb/S) Structured Payload/Test Signal
61
Inserting an External PDH Payload/Test Signal
63
Dropping an External Payload/Test Signal
65
Selecting ATM Cell Stream Payload
67
Selecting ATM Cell Stream Timing Distribution
68
Selecting ATM Cell Stream Headers and Interface
69
Adding Errors & Alarms at the SONET Interface
70
Adding Errors & Alarms to the PDH Interface/Pdh Payload
71
Using FEAC Codes in the HP 37717C
73
Adding ATM Errors and Alarms
76
Setting PDH Spare Bits
77
Adding Pointer Adjustments
78
T1.105/GR-253 Pointer Sequences Explained
80
Using Pointer Graph Test Function
86
Stressing Optical Clock Recovery Circuits
88
Generating Automatic Protection Switch Messages
89
Inserting & Dropping Data Communications Channel
90
3 Making Measurements
92
Using Overhead BER Test Function
93
Test Timing
94
Making SONET Analysis Measurements
95
Making PDH Analysis Measurements
96
Measuring Jitter
98
Measuring Wander
100
Measuring Frequency
102
Measuring Optical Power
103
Measuring Round Trip Delay
104
Monitoring Signaling Bits
106
Measuring Service Disruption Time
108
Performing an SONET Tributary Scan
110
Performing a SONET Alarm Scan
112
Performing a PDH Alarm Scan
114
Selecting the ATM Measurement Parameters
115
Making ATM Measurements
117
Measuring Cell Transfer Delay and Cell Delay Variation
118
Measuring ATM Non-Conforming Cells and One-Point Cell Delay Variation
120
Monitoring ATM Alarms
121
4 Storing, Logging and Printing
122
Saving Graphics Results to Instrument Store
123
Recalling Stored Graph Results
124
Viewing the Bar Graph Display
126
Viewing the Graphics Error and Alarm Summaries
128
Logging Graph Displays
130
Logging Results
131
Logging Results to Parallel (Centronics) Printer
134
Logging Results to HP-IB Printer
135
Logging Results to Internal Printer
136
Logging Results to RS-232-C Printer
137
Printing Results from Disk
138
Connecting an HP Deskjet Printer to a Parallel Port
139
Changing Internal Printer Paper
140
Cleaning Internal Printer Print Head
143
5 Using Instrument and Disk Storage
144
Storing Configurations in Instrument Store
145
Storing Current Configurations on Disk
146
Setting up a Title for Configurations in Instrument Store
147
Recalling Configurations from Instrument Store
148
Formatting a Disk
149
Labeling a Disk
150
Managing Files and Directories on Disk
151
Adding Descriptors to Disk Files
155
Saving Graphics Results to Disk
156
Saving Data Logging to Disk
158
Recalling Configuration from Disk
159
Recalling Graphics Results from Disk
160
Copying Configuration from Instrument Store to Disk
161
Copying Configuration from Disk to Instrument Store
162
Copying Graphics Results from Instrument Store to Disk
163
Deleting a File on Disk
165
Deleting a Directory on Disk
166
Renaming a File on Disk
167
Creating a Directory on Disk
168
6 Selecting and Using "Other" Features
170
Coupling Transmit and Receive Settings
171
Suspending Test on Signal Loss
172
Setting Time & Date
173
Enabling Keyboard Lock
174
Enabling Beep on Received Error
175
Enabling Analysis Control
176
Setting Error Threshold Indication
177
Dumping Display to Disk
178
Setting Screen Brightness and Color
180
Running Self Test
181
7 SPE Background Patterns
186
8 ETSI/ANSI Terminology
188
ETSI/ANSI Conversion and Equivalent Terms
189
