55
Selecting Test Features
Dropping an External Payload/Test Signal
Drop 2 Mb/s /DS1 (Unstructured SDH/SONET Payload)
1 Connect the DEMUX port of the PDH module to the external
equipment.
2 Set up the required transmit SONET interface, and choose DROP
2Mb/s or DS1 (Options 110/120) on the
display.
Drop 2 Mb/s/DS1 (Structured SDH/SONET Payload or
Structured PDH
1 Connect the DEMUX port of the PDH module to the external
equipment.
2 If you chose a structured SONET payload, set up the required receive
SONET interface, and structured payload and choose DROP 2 Mb/s or
DROP DS1 (Option 110) on the display.
If you chose a structured PDH, set up the required receive PDH
interface, set up the required receive Structured Payload/Test Signal and
choose DROP 2 Mb/s or DROP DS1 (Option 110) on the
display.
SONET MAIN SETTINGS
SONET
STRUCT’D PAYLOAD
PDH
STRUCTURED SETTINGS
