73
Selecting Test Features
T1.105/GR-253 Pointer Sequences Explained
Pointer Sequence Notes
Note 1: For SPE pointers the sequence interval is selectable from:
7.5 ms, 10, 20, 30, 34 ms
40 to 100 ms in 10 ms steps, 100 to 1000 ms in 100 ms steps
1, 2, 5, 10 seconds.
For VT pointers the sequence interval is selectable from:
200 ms, 500 ms, 1, 2, 5 and 10 seconds.
Note 2: For SPE pointers the minimum spacing between adjustments is 500 us.
For VT pointers the minimum spacing between adjustments is 2 ms.
