2-11
Installing Accessories
GSC Mezzanine Cards
GSC Mezzanine Cards
Installing GSC Mezzanine Cards
This section provides step-by-step instructions for installing GSC mezzanine
cards into your Model 744 Board Computer.
Preliminary Requirements
Perform the following steps before you install a GSC card:
1 The Model 744 Board Computer must already have a GSC expansion kit
installed.
2 If the Model 744 Board Computer is already installed in your system
chassis, you must remove it. See Chapter 3 of this manual for instructions
on removing and replacing the Model 744.
3 Place the Model 744 Board Computer on a static-free mat on a clean, level
surface.
GSC Mezzanine Card Installation
Follow these steps to install a GSC card onto your Model 744 Board Com-
puter:
1 Working from the back of the Model 744 Board Computer, you can install
GSC graphics cards into either the right-hand or center position, shown in
Figure 2-4.
2 Using Figure 2-4 as a guide, position a card and line up its connector over
the GSC connector on the board computer.
3 Press the card down to seat the connectors.
4 Insert the two M2.5x6 screws that hold the GSC card to the adapter fixture
and screw them into place.
5 Insert the two M2.5x5 screws that hold the card to the front panel expan-
sion plate and screw them into place.
