3-10
Typical Installation in a VME Card Cage
Non-HP Installation
Non-HP Installation
The Model 744 Board Computer’s P2 connector has a local bus on user-
defined pins. Verify that your VME card cage backplane makes no connec-
tions to J2/P2, rows A and C.
Refer to Chapter 7 of IEEE STD 1014-1987 for more information on user-
defined pins used in VME backplane connectors.
