Keyboard and Mouse
Keyboard and Mouse
This section provides step-by-step instructions for connecting a keyboard
and mouse to your Model 744.
1 Unpack your new keyboard and place it near your Model 744.
2 Plug the keyboard cable connector into your Model 744 at the PS/2 con-
nector labeled PS/2 0 Kbd.
NOTE: The keyboard must be connected to PS/2 0 to be operational.
3 Unpack your new mouse and locate the mouse’s black rubber ball in the
mouse box.
4 Remove the ball plate from the bottom of the mouse. Insert the ball and
replace the ball plate.
5 Plug the mouse cable connector into your Model 744 at the PS/2 connec-
tor labeled PS/2 1.
