3-12
Typical Installation in a VME Card Cage
Model 744 Removal
Model 744 Removal
Tools Required
Model 744 removal requires the following tools:
Preliminary Requirements
Perform the following procedure before you remove the board computer
from the VME card cage:
1 Read the steps in “Turning Off the System,” in Chapter 5.
Removing a Model 744
Follow these steps to remove the Model 744 from a VME card cage:
1 Loosen the captive screws at each end of the board computer that hold the
computer in the VME card cage (in Figure 3-3, the screws are labeled 1
and 2 for a single-slot board computer, or 1 through 4 for a dual-slot board
computer).
2 Pull both ejector levers out until the board ejects from the card cage.
Tool Used For
Static grounding wrist strap Preventing static discharge problems
Light-duty flat-tipped screwdriver Loosening card cage screws
