6.3 DISPLAY MODES
The Intel graphics controller supports the following 2D display modes. All modes are applicable
to both analog and digital displays unless otherwise indicated.
Table 6-1. 865G-Based Graphics Display Modes
Table 6-1.
865G-Based Graphics Display Modes
Resolution Notes Bits per pixel Color Depth Refresh Rate (max0
640 x 480 [1] [2] 8 256 85
640 x 480 [1] [2] 16 65K 85
640 x 480 [1] [2] 24 16.7M 85
800 x 600 [1] [2] 8 256 85
800 x 600 [1] [2] 16 65K 85
800 x 600 [1] [2] 24 16.7M 85
1024 x 768 [1] [2] 8 256 85
1024 x 768 [1] [2] 16 65K 85
1024 x 768 [1] [2] 24 16.7M 85
1280 x 1024 [1] [2] 8 256 85
1280 x 1024 [1] [2] 16 65K 85
1280 x 1024 [1] [2] 24 16.7M 85
1600 x 1200 [1] [2] 8 256 85
1600 x 1200 [1] [2] 16 65K 85
1600 x 1200 [1] [2] 32 16.7M 85
1900 x 1440 [1] [3] 8 256 75
1900 x 1440 [1] [3] 16 65K 75
1920 x 1080 [1] [3] [4] 8 256 85
1920 x 1080 [1] [3] [4] 16 65K 85
2048 x 1536 [1] [3] 8 256 85
2048 x 1536 [1] [3] 16 65K 60
2048 x 1536 [1] [3] 32 16.7M 60
NOTES:
[1] 2D
[2] 3D
[3] Analog monitor only
[4] dCRT or HDTV only
NOTE: The IGC is designed for optimum performance with multi-sync analog
Monitors. Digital displays may not provide an image as high in quality, depending on
resolution.
The IGC features a 350-MHz RAMDAC that can directly drive an analog multiscan monitor up to
a 2D resolution of 2048 x 1536 with 32-bit color at 60 Hz. The two digital video output ports are
able to drive a digital display up to 1600 x 1200 at 60 Hz. In dual-channel mode the IGC can drive
a flat panel monitor of up to 2048 x 1536 at 60 Hz or a digital CRT/HDTV of up to 1920 x 1080
at 80 Hz.
hp compaq d330 and d530 Series of Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition - June 2003
6-5
