Chapter 6 Integrated Graphics Subsystem
6.4 PROGRAMMING
The 865G-based graphics controller is configured using PCI configuration registers listed in Table
6-2.
Table 6-2. 815E-Based Graphics Controller PCI Configuration Registers
Table 6-2.
865G-Based Graphics Controller PCI Configuration Registers (GMCH, Function 2)
PCI
Config.
Addr.
Register
Reset
Value
PCI
Config.
Addr.
Register
Reset
Value
00, 01h Vendor ID 8086h 2E, 2Fh Subsystem ID 0000h
02, 03h Device ID 2562h 30-33h Vid. BIOS Base Addr. 0’s
04, 05h Command 0000h 34h Capabilities Pointer D0h
06, 07h Status 0090h 3Ch Interrupt Line 00h
08h Revision ID 01h 3Dh Interrupt Pin 01h
09-0Bh Class Code 030000h 3Eh Min. Grant 00h
0Eh Header Type 00h 3Fh Max. Latency 00h
0Fh BIST 00h DC, DDh Pwr. Mgmt. Capabilities 0001h
10-13h Memory Range Addr. 8 DE, DFh Pwr. Mgmt. Capabilites 0021h
14-17h Mem. Map Range Addr. 0’s E0, E1h Pwr. Mgmt. Control 0000h
2C, 2Dh Subsys. Vendor ID 0000h E2-FFh Reserved --
NOTE:
Assume unmarked locations/gaps as reserved. Refer to Intel documentation for detailed
register descriptions.
The graphics controller is controlled through memory-mapped registers by the appropriate
software driver.
6.5 UPGRADING THE GRAPHICS SUBSYTEM
All models except those that use the USDT form factor are upgradeable by installing an AGP
graphics card into the AGP slot. The upgrade procedure is as follows:
1. Shut down the system through the operating system.
2. Unplug the power cord from the rear of the system unit.
3. Remove the chassis cover.
4. Install the AGP card into the AGP slot.
5. Replace the chassis cover.
6. Reconnect the power cord to the system unit.
7. Power up the system unit.
The BIOS will detect the presence of the AGP card and disable the IGC of the 82865G GMCH.
The IGC cannot operation concurrently with a separate AGP controller card installed but can
operate concurrently with a PCI graphics card. All models provide at least one PCI slot.
hp compaq d330 and d530 Series of Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition - June 2003
6-6
