Technical Reference Guide
2.3.2.5 Microtower Chassis
Figure 2-8 shows the layout for the Microtower (MT) chassis used for the d330 models. Features
include:
Externally accessible drive bay assembly may be configured for minitower (vertical) or
desktop (horizontal) position.
Easy access to expansion slots and all socketed system board components.
Front
Back
Power Supply
Hood Lock
Solenoid
(Optional)
Chassis Fan
AGP Slot
PCI Slot 1
PCI Slot 2
PCI Slot 3
Processor/Heat Sink/Fan
Assembly
Drive Lock
Externally Accessible
Drive Bays
Internal
Drive Bays
Speaker
Figure 2-8. Microtower Chassis Layout, Left Side View
hp compaq d330 and d530 Series Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition - June 2003
2-11
