Chapter 2 System Overview
2.3 MECHANICAL DESIGN
This guide covers six form factors:
♦
♦
♦
♦
♦
♦
Ultra Slim Desktop (USDT) – Very slim design that can be used in a tradition desktop
(horizontal) orientation or as a small tower mounted in the supplied tower stand.
Slim Tower (ST) – Slim design that can be used in a tradition desktop (horizontal) orientation
or as a small tower mounted in the supplied tower stand.
Small Form Factor (SFF) – A small-footprint desktop requiring minimal desk space.
Desktop (DT) – A low-profile ATX-type desktop that satisfies standard expandability needs.
Microtower (µT)- A low-height tower that requires less vertical space than a minitower.
Configurable Minitower – an ATX-type unit providing the most expandability and being
adaptable to desktop (horizontal) or floor-standing (vertical) placement.
The following subsections describe the mechanical (physical) aspects of models.
CAUTION: Voltages are present within the system unit whenever the unit is plugged
into a live AC outlet, regardless of the system's “Power On” condition. Always
!
disconnect the power cable from the power outlet and/or from the system unit
before handling the system unit in any way.
NOTE: The following information is intended primarily for identification purposes
only. Before servicing these systems refer to the applicable Service Reference
Guide. Service personnel should review training materials also available on
these products.
hp compaq d330 and d530 Series Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition– June 2003
