Technical Reference Guide
2.4.8 NETWORK INTERFACE CONTROLLER
All models feature a Broadcom NetXtreme Gigabit Network Interface Controller (NIC) integrated
on the system board. The controller provides automatic selection of 10BASE-T, 100BASE-TX, or
1000BASE-T operation with a local area network and includes power-down, wake-up, and Alert-
On-LAN (AOL), and Alert Standard Format (ASF) features. An RJ-45 connector is provided on
the rear panel.
2.4.9 GRAPHICS SUBSYSTEM
These systems use the 82865 GMCH component that integrates an Intel Extreme Graphics 2
controller that can drive an external VGA monitor. The integrated graphics controller features a
350-MHz DAC implements Dynamic Video Memory Technology (DVMT) to use a portion of
system memory according to the needs of the application. Table 2-5 lists the key features of the
integrated graphics subsystem.
Table 2-5. Integrated Graphics Subsystem Statistics
Table 2-5.
Integrated Graphics Subsystem Statistics
82865G GMCH
Integrated Graphics Controller
Recommended for: Hi 2D,
Entry 3D
Bus Type Integrated Graphics Controller
Mem. Amount (uses system memory)
Mem. Type UMA
DAC Speed 350 MHz
Max. 2D Res. 2048 x 1536
Software Compatibility Quick Draw,
DirectX 8.1, 9.0
Direct Draw,
Direct Show.
Open GL 1.3
MPEG 1/2,
Indeo
Outputs 1 RGB
The GMCH also includes an AGP 8X interface that supports an AGP graphics controller installed
in the AGP slot provided on the ST, SFF, DT, MT, and CMT form factors. The AGP slot includes
both Type 1 and Type 2 retention mechanisms.
hp compaq d330 and d530 Series Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition - June 2003
2-19
