Chapter 3 Processor/Memory Subsystem
3.2 PENTIUM 4 PROCESSOR
These systems each feature an Intel Pentium 4 processor in a FC-PGA478 package mounted with
a passive heat sink in a PGA478 zero-insertion force socket. The mounting socket allows the
processor to be easily changed for servicing and/or upgrading.
3.2.1 PROCESSOR OVERVIEW
The Intel Pentium 4 processor represents the latest generation of Intel’s IA32-class of processors.
Featuring Intel’s NetBurst architecture and Hyper-Threading technology, the Pentium 4
processor is designed for intensive multimedia and internet applications of today and the future
while maintaining compatibility with software written for earlier (Pentium III, Pentium II,
Pentium, Celeron, and x86) microprocessors. Key features of the Pentium 4 processor include:
♦ Hyper-Pipelined Technology – The main processing loop has twice the depth (20 stages) of
the Pentium III allowing for increased processing frequencies.
♦ Execution Trace Cache – A new feature supporting the branch prediction mechanism, the
trace cache stores translated sequences of branching micro-operations (µops) and is checked
when suspected re-occurring branches are detected in the main processing loop. This feature
allows instruction decoding to be removed from the main processing loop.
♦ Rapid Execution Engine – Arithmetic Logic Units (ALUs) run at twice (2x) processing
frequency for higher throughput and reduced latency.
♦ 256- or 512-KB Advanced transfer L2 cache – Using 32-byte-wide interface at processing
speed, the L2 cache can provide an increase of 3x over a Pentium III of equal speed.
♦ Advanced dynamic execution – Using a larger (4K) branch target buffer and improved
prediction algorithm, branch mis
-predictions are reduced by an average of 33 % over the
Pentium III.
♦ Enhanced Floating Point Processor - With 128-bit integer processing and deeper pipelining
the Pentium 4’s FPU provides a 2x performance boost over the Pentium III.
♦ Additional Streaming SIMD extensions (SSE2) – In addition to the SSE support provided by
previous Pentium processors, the Pentium 4 processor includes an additional 144 MMX
instructions, further enhancing:
• Streaming video/audio processing
• Photo/video editing
• Speech recognition
• 3D processing
• Encryption processing
♦ Quad-pumped Front Side Bus (FSB) – The FSB uses a 100-, 133-, or 200-MHz clock for
qualifying the buses’ control signals. However, address information is transferred using a 2x
strobe while data is transferred with a 4x strobe, providing a maximum data transfer rate that
is several times that of a similar-speed Pentium III processor.
hp compaq d330 and d530 Series Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition - June 2003
3-2
