Chapter 2 System Overview
2.2 FEATURES AND OPTIONS
This section describes the standard features and available options.
2.2.1 STANDARD FEATURES
The following standard features are included on all models:
♦ Intel Pentium 4 processor in PPGA478 (Socket N) package
♦ PC2100, PC2700, or PC3200 DIMM support
♦ 48x Max CD-ROM drive
♦ Dual IDE controllers w/UATA100 and serial ATA support
♦ Hard drive fault prediction
♦ Six USB 2.0 ports, one headphone output, one microphone input, ,one line input, one network
interface
♦ Plug ’n Play compatible (with ESCD support)
♦ Intelligent Manageability support
♦ Energy Star compliant
♦ Security features including:
• Flash ROM Boot Block
• Diskette drive disable, boot disable, write protect
• Power-on password
• Administrator password
• Serial/parallel port disable
♦ PS/2 or USB enhanced keyboard
♦ PS/2 or USB scroll mouse
Table 2-1 shows the differences in features between the different PC series based on form factor:
Table 2-1. Feature Difference Matrix
Table 2-1
Difference Matrix by Form Factor
USDT ST SFF DT µT CMT
Series D530 D330 D530 D330 D330 D530
System Board
Type
Proprietary µATX µATX µATX µATX µATX
Series d530 d330 d530 d330 d330 d530
DIMM sockets 2 4 4 4 4 4
Drive bays (total) 2 3 3 5 5 6
AGP slot none Low-profile Low-profile Full size Full size Full size
PCI slots 1 Full-height 3 Low-profile or
2 Full-height [1]
2 Full-height
half-length
3 Full-height 3 Full-height 5 Full-height
Std. # of Serial
I/Fs
none 1 1 1 1 1
Keyboard/Mouse
connection
USB PS/2 PS/2 PS/2 PS/2 PS/2
Smart Cover
Sensor / Lock
No Optional Optional Optional Optional Opltional
Power Supply 150-watt PFC 185-watt PFC 185-watt PFC 250-watt
PFC
250-watt
PFC
250-watt PFC
NOTE:
[1] Customer must specify configuration at time of purchase.
hp compaq d330 and d530 Series Personal Computers
Featuring the Intel Pentium 4 Processor
First Edition– June 2003
2-2
