HP EliteOne 800 G4 User Manual

Webcam module
The webcam is located at the top of the computer, under a plastic shield. The top heat sink screws also secure
the webcam plastic shield.
To remove the webcam module:
NOTE: Webcam appearance may vary.
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 18).
2. Remove the rear port cover (see Removing the rear port cover on page 18).
3. Remove the stand (see Stands on page 19).
4. Remove the access panel (see Access panel on page 20).
5. If a discrete heat sink is installed, remove the VESA mounting bracket/fan assembly (see VESA mounting
bracket/fan assembly on page 38).
6. Remove the heat sink (see Heat sink on page 33).
7. To remove the webcam plastic shield, remove the two Torx screws (1), and then remove the webcam
shield from the computer (2).
8. Remove the two Phillips screws (1) that secure the webcam assembly to the computer.
9. Disconnect the webcam cable from the system board (2).
Webcam module 35

HP EliteOne 800 G4 Specifications

General

RAM	Up to 64GB DDR4
Storage	Up to 2TB HDD or 1TB SSD
Display	23.8"
Graphics	Intel UHD Graphics 630
Operating System	Windows 10 Pro
Audio	Bang & Olufsen speakers
Networking	Intel Dual Band Wireless-AC 9560, Bluetooth 5.0, Gigabit Ethernet
Ports (Front)	headphone/microphone combo jack
Ports (Rear)	USB 2.0, RJ-45, audio line-out
