10. Remove the webcam cable from the routing path in the webcam bracket and the clips built into the
computer (3).
NOTE: The webcam is white on healthcare models.
11. Remove the webcam assembly from the computer.
12. If you need to remove the webcam bracket, remove the VESA bracket/fan assembly (VESA mounting
bracket/fan assembly on page 38), and then remove the four Torx screws (1) that secure the webcam
bracket to the computer.
36 Chapter 4 Removal and Replacement Procedures
