Ground Bonding kit
Kit overview
The Ground Bonding kit reduces the electromagnetic emissions outside of the racks. These emissions are produced during
normal operation of the electronic components within the rack. Typically, rack-mounted equipment must meet class A
emissions levels, but you might want to reduce these levels even further. Use this kit to tie all the conductive structural
components together with conductive cables, and then attach the kit to a ground bonding point on the AC power distribution
device of the rack or the building ground.
Kit contents (P9L11A)
Item Quantity
1524-cm (6-in) grounding straps 2
3683-cm (145-in) grounding straps 3
1524-cm (6-in) grounding straps (with a connector on one
end)
4
3683-cm (145-in) grounding straps (with a connector on
one end)
4
M8 nut 8
Internal serrated lock washer 8
M8 x 20 hex head screw 1
Self-tapping 55 x 10 screw 8
62 Paint cutter washer 1
84 Paint cutter washer 1
M6 x 10 low HD cap screw 1
Required tools
The following tools are required for installation:
• T-25 Torx driver
• M8 socket
Installing the ground bonding kit
Procedure
1. Attach the appropriate grounding straps from the system chassis to the front door.
2.
Attach the appropriate grounding straps from the system chassis rail to the rear doors.
3. Attach the appropriate grounding straps from the system chassis rail to the rack top.
4.
Attach the appropriate grounding straps from the rack to a building facility.
Ground Bonding kit
34
