2-17
GVRP
GVRP Operating Notes
Web: Viewing and Configuring GVRP
To view, enable, disable, or reconfigure GVRP:
1. Click on the Configuration tab.
2. Click on
[VLAN Configuration] and do the following:
• To enable or disable GVRP, click on GVRP Enabled.
• To change the Unknown VLAN field for any port:
i. Click on
[GVRP Security] and make the desired changes.
ii. Click on
[Apply] to save and implement your changes to the
Unknown VLAN fields.
For web-based Help on how to use the WebAgent screen, click on the
[?] button
provided on the WebAgent screen.
GVRP Operating Notes
â– A dynamic VLAN must be converted to a static VLAN before it can have
an IP address.
â– On the switches covered in this guide, GVRP can be enabled only if max
vlans is set to no more than 256 VLANs.
â– The total number of VLANs on the switch (static and dynamic combined)
cannot exceed the current Maximum VLANs setting. For example, in the
factory default state, the switch supports up to 256 VLANs. Any additional
VLANs advertised to the switch will not be added unless you first increase
the Maximum VLANs setting. In the Menu interface, click on
2. Switch
Configuration …
| 8. VLAN Menu | 1. VLAN Support. In the global config level of the
CLI, use
max-vlans.
â– Converting a dynamic VLAN to a static VLAN and then executing the write
memory command saves the VLAN in the startup-config file and makes it
a permanent part of the switch’s VLAN configuration.
â– Within the same broadcast domain, a dynamic VLAN can pass through a
device that is not GVRP-aware. This is because a hub or a switch that is
not GVRP-ware will flood the GVRP (multicast) advertisement packets
out all ports.
â– GVRP assigns dynamic VLANs as Tagged VLANs. To configure the VLAN
as Untagged, you must first convert it to a static VLAN.
