HP J8697A Advanced Traffic Management Guide

1-43
Static Virtual LANs (VLANs)
Configuring VLANs
Note You cannot use these commands with dynamic VLANs. Attempting to do so
results in the message “VLAN already exists.” and no change occurs.
WebAgent: Viewing and Configuring VLAN Parameters
In the WebAgent you can do the following:
■ Add VLANs
■ Rename VLANs
■ Remove VLANs
■ Configure VLAN tagging mode per-port
■ Configure GVRP mode
■ Select a new Primary VLAN
■ Enable/disable QinQ
■ Set Max VLANS
To configure other static VLAN port parameters, you will need to use either
the CLI or the menu interface (available by Telnet from the WebAgent).
1. Click on the VLAN folder.
2. Click on
VLAN Mgmt.
3. Click on the appropriate button for the desired task.
For web-based Help on how to use the WebAgent screen, click on the
[?] button
in the upper right corner of the WebAgent screen.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
