HP J8697A Advanced Traffic Management Guide

8-43
Classifier-Based Software Configuration
Zone Classes
Figure 8-15. Example of a Zone Class Configuration
Creating a Zone Policy
1. To create a zone policy that performs zone-specific actions on selected
packets, enter the policy zone <policy-name> command from the global
configuration context.
A zone policy consists of one or more actions that are configured for
specific zones.
No action is performed on packets sent to or from ports in the BYPASS
zone. By default, ports are assigned to the BYPASS zone unless you
explicitly assign them to a different zone.
Context: Global configuration
Syntax: [no] policy zone <policy-name >
Defines the name of a service policy and enters the policy
configuration context, where <policy-name > is a text string
(64 characters maximum). Note that this name should not
be the same as a zone name.
HP Switch(config)# class zone internal
HP Switch(config-class)# port-list a10-a24
HP Switch(config-class)# exit
HP Switch(config)# class zone external
HP Switch(config-class)# port-list a1
HP Switch(config-class)# exit

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
