HP J8697A Advanced Traffic Management Guide

3-81
Multiple Instance Spanning-Tree Operation
STP Loop Guard
Figure 3-41. Example of Spanning-tree Configuration Information
Detailed Spanning Tree information is shown in Figure 3-42.
HP Switch(config)# show spanning-tree config
Multiple Spanning Tree (MST) Configuration Information
STP Enabled [No] : Yes
Force Version [MSTP-operation] : MSTP-operation
Default Path Costs [802.1t] : 802.1t
MST Configuration Name : 0024a8d13a40
MST Configuration Revision : 0 Switch Priority : 32768
Forward Delay [15] : 15 Hello Time [2] : 2
Max Age [20] : 20 Max Hops [20] : 20
| Path Prio Admin Auto Admin Hello Root Loop TCN BPDU
Port Type | Cost rity Edge Edge PtP Time Guard Guard Guard Flt
---- --------- + --------- ---- ----- ---- ----- ------ ----- ----- ----- ---
1 100/1000T | Auto 128 No Yes True Global No No No No
2 100/1000T | Auto 128 No Yes True Global No Yes No No
3 100/1000T | Auto 128 No Yes True Global No No No No
4 100/1000T | Auto 128 No Yes True Global No No No No
5 100/1000T | Auto 128 No Yes True Global No No No No
6 100/1000T | Auto 128 No Yes True Global No No No No
.
.
.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
