HP J8697A Advanced Traffic Management Guide

6-4
Stack Management for the 3500, 3500yl, 6200yl and 6600 Switches
Introduction to Stack Management on the 3500, 3500yl, 6200yl and 6600 Switches
Figure 6-2. Example of Stacking with One Commander Controlling Access to Wiring Closet Switches
Interface Options. You can configure stacking through the switch’s menu
interface, CLI, or the WebAgent For information on how to use the WebAgent
to configure stacking, see the online Help by clicking on the “?” in the
WebAgent screen.
Member Switch 1
IP Address: None Assigned
Manager Password: leader
Candidate Switch
IP Address: None Assigned
Manager Password: francois
Non-Member Switch
IP Address: 10.28.227.105
Manager Password: donald
Member Switch 2
IP Address: None Assigned
Manager Password: leader
Wiring Closet "B"
Wiring Closet "A"
Commander Switch 0
IP Address: 10.28.227.100
Manager Password: leader
Use the Commander’s console or
WebAgent to access the user
interface on any Member switch in
the same stack.
Network Backbone
