Installing Accessories
Using the Module Bay Adapter
1-42
9. Remove the cover plate from the module bay slot by pressing down on the two
tabs and pushing it out..
10. Remove and save the locking screw from the module bay housing.
11. Insert the module adapter for your OmniBook plug-in modules into the module
bay until it locks in place.
12. Re-install the locking screw in the hole in the top of the module bay housing to
secure the module adapter in the bay. This screw prevents removal of the
module adapter from the dock.
