HP ProCurve 1810G User Manual

4-1
4
Switching Pages
You can use the Switching Pages to configure port operation and capabilities.
Port Configuration
Use the Port Configuration page to view and configure parameters for port operation. To access this
page, click
Switching > Port Configuration in the navigation pane.
Figure 4-1. Port Configuration Page
Note The display and the content of this page changes based on the physical port selected. For example, if
the selected port is an optional copper/fiber port and fiber is being used, than the Link Speed selections
will display only valid options for that port.
Table 4-1. Port Configuration Fields
Field Description
Interface Select the interface to configure.
Physical Type Describes the port type (i.e., Copper or Fiber).
Link Status Displays Up or Down to indicate operational status.
Admin Mode Select to enable access to the port on the network. Clear to disable the port.

HP ProCurve 1810G Specifications

General

Model	HP ProCurve 1810G
Layer	Layer 2
Power Supply	Internal
VLAN Support	Yes, up to 256 VLANs
Ports	8 or 24 10/100/1000 ports
Management	Web-managed
Switching Capacity	16 Gbps (8-port), 48 Gbps (24-port)
Form Factor	Rack-mountable
Forwarding Rate	11.9 Mpps (24-port model)
Jumbo Frame Support	Yes
Quality of Service (QoS)	Yes
Operating Temperature	0°C to 40°C
Operating Humidity	15% to 95% non-condensing
