Rear panel components

1 Line-In Audio Connector (blue) 7 USB 3.0 Ports (blue)

2 RJ-45 Network Connector 8 USB 2.0 Ports (black)

3 Serial Connector 9 USB 2.0 Ports with Wake from S4/S5

feature (black)

4 PS/2 Mouse Connector (green) 10 DisplayPort Monitor Connector

5 Power Cord Connector 11 VGA Monitor Connector

6 Line-Out Connector for powered audio devices

(green)

12 PS/2 Keyboard Connector (purple)

NOTE: An optional second serial port and an optional parallel port are available from HP.

If using a USB keyboard, HP recommends connecting the keyboard to one of the USB 2.0 ports with the wake from S4/S5

feature. The wake from S4/S5 feature is also supported on the PS/2 connectors if enabled in BIOS F10 Setup.

When a graphics card is installed in one of the system board slots, the video connectors on the graphics card and the

integrated graphics on the system board may be used at the same time. However, for such a conguration, only the display

connected to the discrete graphics card will display POST messages.

The system board graphics can be disabled by changing settings in Computer Setup.

ProDesk 400 3
