HP ProDesk 490 G3 MT User Manual

Card reader
Description
Card reader, USB 3.0
Card reader, USB 2.0
The card reader is attached to the front of the chassis.
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the access panel (Access panel on page 24).
3. Remove the front bezel (Front bezel on page 25).
4. From the outside, front of the chassis, remove the Torx T15 screw that secures the card reader.
5. From the inside of the chassis, disconnect the card reader cable from the system board labeled SD RDR,
and then press the tab on the side of the card reader (1) and slide the card reader out the front of the
chassis (2).
To install the card reader, reverse the removal procedures.
Card reader 51

HP ProDesk 490 G3 MT Specifications

General

Operating System	Windows 10 Pro
Form Factor	Microtower
Memory Slots	2 DIMM
Memory Type	DDR4-2133
Maximum Memory	32 GB
Weight	7.05 kg
Processor	Intel Core i5, i3
RAM	Up to 32GB DDR4
Storage	500 GB HDD
Graphics	Intel HD Graphics 530
Chipset	Intel H110 Chipset
Internal Drive Bays	1 x 3.5"
External Drive Bays	1 x 5.25"
Expansion Slots	1 PCIe x16
Ports (Front)	2 USB 3.0
Ports (Rear)	1 VGA
Audio	Realtek ALC221
Optical Drive	DVD-Writer
