Expansion cards
Description
Nvidia GeForce GT730 DP PCIe x8 graphics card, 2 GB
Nvidia GeForce GT720 DP PCIe x8 graphics card, 2 GB
AMD R9 350 2 GB graphics card (DDR5, PCIe x16)
Intel PRO/1000 single port GbE, NIC
PCI adapter – WLAN module
Printer port, PCI card
Serial port, PCI card
(ProDesk 400) The computer has three PCI Express x1 expansion sockets and one PCI Express x16 expansion
socket.
(ProDesk 480) The computer has one PCI expansion socket, two PCI Express x1 expansion sockets, and one
PCI Express x16 expansion socket.
(ProDesk 490) The computer has two PCI Express x1 expansion sockets, one PCI Express x16 expansion
socket, and one PCI Express x16 expansion socket that is downshifted to a x4 socket.
NOTE: You can install a PCI Express x1, x8, or x16 expansion card in the PCI Express x16 socket.
For dual graphics card congurations, the rst (primary) card must be installed in the PCI Express x16 socket.
To remove, replace, or add an expansion card:
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the access panel (Access panel on page 24)
3. Remove the screw that holds down the expansion card retention latch (1), and then slide the latch up (2)
and pull it o the rear of the chassis (3).
Expansion cards 31
