HP ProDesk 490 G3 MT User Manual

NOTE: After installing a new processor onto the system board, update the system ROM to ensure that the
latest version of the BIOS is being used on the computer. The latest system BIOS can be found on the Web at:
http://h18000.www1.hp.com/support/les.
Speaker
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the access panel (Access panel on page 24).
3. From the outside front of the chassis, remove the Torx screw that secures the speaker to the front of the
chassis.
4. From the inside of the chassis, disconnect the speaker cable from the system board connector labeled
SPKR.
NOTE: System board appearance may vary.
5. Remove the speaker cable from the clip built into the base of the chassis (1).
58 Chapter 4 Removal and replacement procedures: Microtower

HP ProDesk 490 G3 MT Specifications

General

Operating System	Windows 10 Pro
Form Factor	Microtower
Memory Slots	2 DIMM
Memory Type	DDR4-2133
Maximum Memory	32 GB
Weight	7.05 kg
Processor	Intel Core i5, i3
RAM	Up to 32GB DDR4
Storage	500 GB HDD
Graphics	Intel HD Graphics 530
Chipset	Intel H110 Chipset
Internal Drive Bays	1 x 3.5"
External Drive Bays	1 x 5.25"
Expansion Slots	1 PCIe x16
Ports (Front)	2 USB 3.0
Ports (Rear)	1 VGA
Audio	Realtek ALC221
Optical Drive	DVD-Writer
