Access panel
To access internal components, you must remove the access panel:
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Loosen the thumbscrew on the rear of the computer (1), and then slide the panel back (2) and lift if o
the computer (3).
NOTE: System appearance may vary.
24 Chapter 4 Removal and replacement procedures: Microtower
