Illustrated parts catalog 16

Illustrated parts catalog

Mechanical components

Item Description Spare part number Customer self

repair (on page 5)

1 Primary access panel 454347-001 Mandatory

2 9.5-mm optical drive bracket* 460014-001 Mandatory

3 PCI riser board assembly 458749-001 Mandatory

4 2-bay hard drive cage with (optical drive blank) 458751-001 Mandatory

5 4-bay hard drive cage with (optical drive blank) 458750-001 Mandatory

6 Front I/O assembly 457870-001 Mandatory

7 Miscellaneous plastics and hardware kit 459732-001 Mandatory

a) Processor air baffle — —

b) Left bezel (4-bay hard drive cage model) — —

c) Right bezel (4-bay hard drive cage model) — —

d) Bezel (2-bay hard drive cage model)* — —

e) Air blocker — —

f) Foam cable guide* — —
