HP ProLiant DL320 Generation 5p Maintenance And Service Guide

Removal and replacement procedures 41
6.
Disconnect cables from any other devices installed in the hard drive cage, if installed.
7. Remove the cache battery, if installed ("Cache battery" on page 33).
8. Remove all hard drives ("Hard drive" on page 30).
9. Remove the hard drive cage ("Hard drive cage" on page 39).
10. Remove the backplane:
o Two-bay models
o Four-bay models
To replace the component, reverse the removal procedure.
PCI riser board assembly
CAUTION: To prevent damage to the server or expansion boards, power down the server and
remove all AC power cords before removing or installing the PCI riser board assembly.

HP ProLiant DL320 Generation 5p Specifications

General

Processor Sockets	1
Memory Slots	4
Storage	SATA or SAS
Form Factor	1U rackmount
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 3000, 3200 series
Memory	Up to 8GB DDR2
Drive Bays	2 x 3.5" Non-hot plug SATA or SAS
Expansion Slots	1 PCI-Express x8, 1 PCI-Express x4
