Removal and replacement procedures 46
2.
Remove the protective cover from the heatsink.
CAUTION: Heatsink retaining screws should be tightened or loosened in diagonally opposite
pairs (in an "X" pattern). Do not overtighten the screws as this can damage the board,
connectors, or screws. Use the wrench supplied with the system to reduce the possibility of
overtightening the screws.
3. Install the heatsink.
4. Install the air baffle ("Processor air baffle" on page 32).
5. Install the access panel ("Primary access panel" on page 29).
Processor
To remove the component:
