HP ProLiant DL320 Generation 5p Maintenance And Service Guide

Removal and replacement procedures 45
b.
Fully loosen the screws to free the heatsink, being careful not to remove the screw assemblies
from the heatsink.
6. Remove the heatsink.
To replace the component:
IMPORTANT: When replacing the heatsink, check the label on top to be sure the heatsink is
properly oriented.
1. Use the alcohol swab to remove all the existing thermal grease from the processor. Allow the alcohol
to evaporate before continuing.
CAUTION: After the cover is removed, do not touch the thermal interface media.
CAUTION: The heatsink thermal interface media is not reusable and must be replaced if the
heatsink is removed from the processor after it has been installed.

HP ProLiant DL320 Generation 5p Specifications

General

Processor Sockets	1
Memory Slots	4
Storage	SATA or SAS
Form Factor	1U rackmount
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 3000, 3200 series
Memory	Up to 8GB DDR2
Drive Bays	2 x 3.5" Non-hot plug SATA or SAS
Expansion Slots	1 PCI-Express x8, 1 PCI-Express x4
