HP ProLiant DL320 Generation 5p Maintenance And Service Guide

Component identification 70
Item Description
23 Reserved
24 SATA connector 5 (optical drive)*
25 Internal USB option connector
26 Reserved
27 SATA connector 3 (hard drive)
28 SATA connector 1 (hard drive)
29 Parallel option connector
30 Serial option connector
31 Reserved
32 PCI Express expansion slot 4
33 PCI Express expansion slot 5**
34 Reserved
35 Reserved
36 Reserved
37 Dedicated iLO2 optional module connector
* The server supports one optical drive that can be connected to either SATA connector 5 or SATA connector 6.
**x8 PCI Express cards are supported, but will run at x1 speeds.
System maintenance switch
Position Default Function
S1 Off Off = iLO 2 security is enabled
On = iLO 2 security is disabled
S2 Off Off = Normal operation
On = RBSU will not commit any
configuration changes*
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password enabled
On = Power-on password disabled*
S6 Off Off = Normal operation
On = BIOS will clear CMOS and
NVRAM*
S7 Off Reserved
S8 Off Reserved
* "On" activates the function.

HP ProLiant DL320 Generation 5p Specifications

General

Processor Sockets	1
Memory Slots	4
Storage	SATA or SAS
Form Factor	1U rackmount
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 3000, 3200 series
Memory	Up to 8GB DDR2
Drive Bays	2 x 3.5" Non-hot plug SATA or SAS
Expansion Slots	1 PCI-Express x8, 1 PCI-Express x4
