Removal and replacement procedures 47

WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the

internal system components to cool before touching them.

CAUTION: To prevent possible server malfunction, do not mix processors of different speeds or

cache sizes.

1. Power down the server (on page 27).

2. Remove the server from the rack (on page 28).

3. Remove the primary access panel ("Primary access panel" on page 29).

4. Remove the air baffle ("Processor air baffle" on page 32).

5. Remove the heatsink ("Heatsink" on page 44).

6. Open the processor retaining latch and the processor socket retaining bracket.

7. Using your fingers, remove the failed processor.

To replace the component:
