HP ProLiant DL320 Generation 5p Maintenance And Service Guide

Illustrated parts catalog 21
Item Description Spare part number Customer self repair
(on page 5)
k) 2.66-GHz Intel® Xeon® 3075, 4-MB L2
cache*
454526-001 Optional
2
l) 2.13-GHz Intel® Xeon® X3210, 8-MB L2
cache*
457020-001 Optional
2
m) 2.40-GHz Intel® Xeon® X3220, 8-MB L2
cache*
454529-001 Optional
2
n) 2.50-GHz Intel® Xeon® X3320, 6-MB L2
cache*
463508-001 Optional
2
o) 2.66-GHz Intel® Xeon® X3350, 12-MB L2
cache*
463507-001 Optional
2
p) 2.83-GHz Intel® Xeon® X3360, 12-MB L2
cache*
469859-001 Optional
2
18 PC2-6400 ECC RoHS DIMM — —
a) 512-MB* 459931-001 Mandatory
1
b) 1-GB* 459932-001 Mandatory
1
c) 2-GB* 460424-001 Mandatory
1
System components
19 Fan assembly 457873-001 Mandatory
1
20 Power supply, 400-W 460004-001 Mandatory
1
21 Heatsink 480901-001 Mandatory
1
Boards
22 System board 454510-001 Optional
2
23 SAS/SATA backplane, primary (2-bay and 4-bay
hard drive cage models)
454513-001 Optional
2
24 SAS/SATA backplane, secondary (4-bay hard
drive cage models only)*
454514-001 Optional
2
25 PCIe x8 riser board* 454512-001 Optional
2
26 PCIe x1 riser board* 454511-001 Optional
2
27 PCI-X riser board* 454517-001 Optional
2
28 SATA-PATA interposer board* 454515-001 Optional
2
29 Dedicated iLO connector module 454519-001 Optional
2
Mass storage devices
30 Optical drives — —
a) DVD-RW drive, 12.7-mm (2-bay hard drive
cage models only)*
399403-001 Mandatory
1
b) DVD-ROM drive, 12.7-mm (2-bay hard drive
cage models only)*
397930-001 Mandatory
1
c) DVD-ROM drive, 9.5-mm (4-bay hard drive
cage models only)*
436951-001 Mandatory
1

HP ProLiant DL320 Generation 5p Specifications

General

Processor Sockets	1
Memory Slots	4
Storage	SATA or SAS
Form Factor	1U rackmount
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Processor	Intel Xeon 3000, 3200 series
Memory	Up to 8GB DDR2
Drive Bays	2 x 3.5" Non-hot plug SATA or SAS
Expansion Slots	1 PCI-Express x8, 1 PCI-Express x4
