Hardware options installation 38
CAUTION: Close and hold down the processor cover socket while closing the processor
locking levers. The levers should close without resistance. Forcing the levers closed can
damage the processor and socket, requiring system board replacement.
11. Remove the heatsink cover.
CAUTION: After the cover is removed, do not touch the thermal interface media.
12. Install the heatsink:
a. Position the heatsink on the processor backplate.
b. Tighten one pair of diagonally opposite screws halfway, and then tighten the other pair of screws.
c. Finish the installation by completely tightening the screws in the same sequence.
