Hardware options installation 78
1.
Back up all server data.
2. Power down the server (on page 21).
3. Do one of the following:
o Extend the server from the rack (on page 21).
o Remove the server from the rack (on page 22).
4. Remove the access panel (on page 22).
5. Install the HPE Smart Array P440ar controller.
6. Connect the SAS/SATA cables to the backplane and Smart Array controller. Install the SAS/SATA
cables according to their labels as Port 1 or Port 2. These labels are on the cables and their
connections.
o 8SFF
